Hydraulic Decoiler MT-F
- Model
- MT-F
Review
Description
Product Description
Hydraulic Decoiler MT-F
Product Features
1.Suitable for all kinds of coil material feeding and receiving, sheet metal and non-metallic materials.
2.The brake device is adjustable in tightness, and the spindle adopts the reinforced type, which makes the material reel rotate more smoothly and increases the load force.
3.Adopt imported parts, less failure, long life.
4.Expansion mode can choose manual expansion or hydraulic expansion, can add pressure arm, variable frequency speed regulation, trolley, etc.
5.Can be customized according to the material situation.
SPECIFICATION PARAMETER
|
Model
|
MT-400F | MT-500F |
MT-600F
|
MT-700F
|
MT-800F
|
MT-1000F | MT-1200F |
Width of material (mm) | 400 | 500 | 600 | 700 | 800 | 1000 | 1200 |
Thickness of material (mm) | 0.1-3.2 | ||||||
Coil I.D.(mm) | 450-530 | ||||||
Coil O.D.(mm) | 1200 | ||||||
|
Coil Weight(kg)
|
3000 |
5000
|
|||||
Expansion | Hydraulic Expansion | ||||||
Pressing Arm | Pneumatic Type Pressing Arm | ||||||
|
Inverter
|
Delta, Taiwan |
||||||
|
Speed
|
16 m/min |
||||||
Product Display
